Processor | Intel Core™ Ultra 5 228V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 8MB Intel® Smart Cache |
AI PC Category | Copilot+ PC |
NPU | Integrated Intel® AI Boost, up to 40 TOPS |
Graphics | Integrated Intel® Arc™ Graphics 130V |
Chipset | Intel® SoC Platform |
Memory | 32GB Soldered LPDDR5X-8533, MoP Memory |
Memory Slots | Lunar Lake: memory soldered to systemboard, no slots, dual-channel |
Max Memory | Lunar Lake: 32GB soldered memory, not upgradable |
Storage | 512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
Storage Slot | Models with V or H series processor: one M.2 2280 PCIe® 5.0 x4 slot |
Max Storage Support | One drive, up to 2TB M.2 2280 SSD |
Card Reader | No Card Reader |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audio™ |
Microphone | 2x, 360° |
Camera | 5.0MP + IR Discrete with Privacy Shutter |
Battery | 57Wh |
Power Adapter | 65W USB-C® (3-pin) |
DESIGN |
Display | 14" WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz, DBEF5 |
Touchscreen | None |
Screen-to-Body Ratio | 85.73% |
Pen | Pen Not Supported |
Keyboard | Backlit, English |
Dimensions (WxDxH) | 315.9 x 223.7 x 10.9/16.13 (front/rear), 21.8 (maximum) mm;
12.44 x 8.81 x 0.43/0.64 (front/rear), 0.86 (maximum) inches |
Weight | Starting at 1.38 kg (3.05 lbs) |
Case Color | Black |
Case Material | PC + 20% CF (Top), PC + 20% CF (Bottom) |
SOFTWARE |
Operating System | None |
Bundled Software | None |
CONNECTIVITY |
WLAN + Bluetooth | Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4 |
WWAN | WWAN Not Supported |
SIM Card | No physical SIM card inbox |
Ethernet | 100/1000M (RJ-45) |
NFC | No NFC |
Standard Ports | 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45)
|
Optional Ports (configured) | None |
Docking | Various docking solutions supported via Thunderbolt™ / USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® T14 Gen 6 (Intel®) |
SECURITY & PRIVACY |
ThinkShield | ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | Kensington Nano Security Slot™, 2.5 x 6 mm |
Smart Card Reader | No Smart Card Reader |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | |
MANAGEABILITY |
System Management | Non-vPro® |
SERVICE |
Base Warranty | 1-year, Courier or Carry-in |
Included Upgrade | 3Y Premier Support Upgrade from 1Y Courier/Carry-in |
